Stage EKS 310_412

Medium/high level order picker 1.0 - 1.2t

All models
Choose model
  • All models
  • EKS 310 Z
  • EKS 310 L
  • EKS 310 O
  • EKS 412 Z
  • EKS 412 L
  • EKS 412 O
  • 7000 - 9000 mm
  • 1200 kg
  • Ergonomic and individually adjustable operating concept.
  • Optimum view and visibility in warehouse operations.
  • Perfectly designed for use in wide aisles.
  • High driving stability for safe and ergonomic operation.
  • Can be extended with the three-stage Jungheinrich DT mast.

EKS 310/ 412

The efficient EKS 412 and EKS 310 medium/high level order pickers are optimised for use in your warehouse thanks to their outstanding travel and lift performance. With excellent ergonomics and picking performance, the two new energy-saving and freely movable 24-V models excel in wide-aisle warehouses. Thanks to the extended mast portfolio, order picking heights of more than 10 meters can be reached effortlessly. With a wide range of individual equipment options, the two vertical order pickers are versatile in their use and create a particularly ergonomic work environment thanks to an optimised operating concept coupled with perfect all-round visibility. Whether with powerful lithium-ion power or lead-acid batteries: Our new EKS 412 and EKS 310 medium/high level order pickers combine optimum picking performance with impressive energy efficiency.

Li-Ion

Content Li-Ionen + 5 Jahre Logo
No worries. No compromise.

The Jungheinrich Li-ion Guarantee Plus offers up to 8 years of reliable performance for our high-quality lithium-ion batteries. Confident in their high performance and long service life, we also guarantee a hassle-free switch back to your original technology within 6 months of delivery.


Features

Model Overview

Model Load capacity Lift height Travel speed Overall length Battery voltage
EKS 310 Z 1 000 kg 7 000 mm 10 km/h 3 095 mm 24 V
EKS 310 L 1 000 kg 7 000 mm 10 km/h 3 140 mm 24 V
EKS 310 O 1 000 kg 7 000 mm 10 km/h 3 085 mm 24 V
EKS 412 Z 1 200 kg 9 000 mm 10 km/h 3 285 mm 24 V
EKS 412 L 1 200 kg 9 000 mm 10 km/h 3 330 mm 24 V
EKS 412 O 1 200 kg 9 000 mm 10 km/h 3 275 mm 24 V
